Calculate machine utilization
Question:
I need to calculate how many hours a machine is utilized in a company with a night and day shift?
The day shift hours:
Mon: 06:15 AM - 3:15 PM
Tue: 06:15 AM - 3:15 PM
We: 06:15 AM - 3:15 PM
Thu: 06:15 AM - 3:15 PM
Fri: 06:15 AM - 11:15 AM
Sat:
Sun:
The night shift hours:
Mon: 8:00 PM - 12:00 AM
Tue: 8:00 PM - 12:00 AM
We: 8:00 PM - 12:00 AM
Thu: 9:00 PM - 12:00 AM
Fri: 12:00 AM - 2:45 AM
Sat:
Sun:
Machine utilization date and time range
Start date and time: 1/2/2027 08:00 AM
End date and time: 1/11/2027 12:00 PM
The image above shows the start date and time value in cell C4 and end date and time value in cell C5. This date and time range will overlap the day and night shift hours, some times overlap multiple times.
| Date | Weekday number | Time | |
| Start date: | 1/2/2027 8:00 AM | 6 | 8:00:00 AM |
| End Date: | 1/11/2027 12:00 PM | 1 | 12:00:00 PM |
Cell B9 to E19 contains the day and night shift hours specified per weekday. This example shows a week starting with Monday to Sunday with corresponding weekday numbers in cells B9 to B19. These numbers are important, they allow for calculating time total based on an overlapping day and night shift schedule.
| Weekday | Weekday number | Start time | End time |
| Mon | 1 | 6:15 AM | 3:15 PM |
| Mon | 1 | 8:00 PM | 12:00 AM |
| Tue | 2 | 12:00 AM | 3:15 PM |
| Tue | 2 | 8:00 PM | 12:00 AM |
| Wed | 3 | 12:00 AM | 3:15 PM |
| Wed | 3 | 8:00 PM | 12:00 AM |
| Thu | 4 | 12:00 AM | 2:45 AM |
| Thu | 4 | 6:15 AM | 3:15 PM |
| Thu | 4 | 9:00 PM | 12:00 AM |
| Fri | 5 | 12:00 AM | 2:45 AM |
| Fri | 5 | 6:15 AM | 11:15 AM |
Formula in cell F21:
Date and time range 1/2/2027 8:00 AM - 1/11/2027 12:00 PM overlaps these day and night shift ranges:
| Weekday | Weekday num | Start time | End time | Total hours |
| Mon | 1 | 6:15 AM | 3:15 PM | 14:45:00 |
| Mon | 1 | 8:00 PM | 12:00 AM | 4:00:00 |
| Tue | 2 | 12:00 AM | 3:15 PM | 15:15:00 |
| Tue | 2 | 8:00 PM | 12:00 AM | 4:00:00 |
| Wed | 3 | 12:00 AM | 3:15 PM | 15:15:00 |
| Wed | 3 | 8:00 PM | 12:00 AM | 4:00:00 |
| Thu | 4 | 12:00 AM | 2:45 AM | 2:45:00 |
| Thu | 4 | 6:15 AM | 3:15 PM | 9:00:00 |
| Thu | 4 | 9:00 PM | 12:00 AM | 3:00:00 |
| Fri | 5 | 12:00 AM | 2:45 AM | 2:45:00 |
| Fri | 5 | 6:15 AM | 11:15 AM | 5:00:00 |
The right-most column in the table above contains the total time per each day and night shift schedule in a week. The following formula creates this dynamic array shown in cell range F9:F19.
Formula in cell F9:
This formula in cell F9 is similar to the formula in cell F24, the difference is that the formula breaks down the hours per each day in the given date and time range specified in cells C4 and C5. The formula in cell F9 breaks down the total per schedule row given in cell range B9:F19.
The formula in cell F24 is the same as in cell F21 with one exception, the SUM function is removed. This creates a dynamic array that spills to cells below automatically as far as needed. If you change the date and time range in cells C4 and C5 the formula automatically adjusts the output. This is great for a breakdown of the hours for each day in the given date and time range.
This example shows a date and time range that overlaps Mondays twice which creates a larger total for that day than the specified time range. For example, 3:15 PM - 6:15 AM is 9:00 hours but the total is 14:45:00 for the first row in the day and night schedule. This is explained by the date and time range overlapping this time range twice making the total larger than the given time range.
If you add the time intervals in cell range F9:F19 you will get 79:45 hours, you will get the same result if you add the time intervals in cells F24:F33.
Explaining the formula
The MEDIAN function allows you to calculate the overlapping time range based on two date and time ranges.
MEDIAN(Start1,End1,End2) - MEDIAN(Start1,End1,Start2)
- Start1 is the starting point for date and time range 1
- End1 is the ending point for date and time range 1
- Start2 is the starting point for date and time range 2
- End2 is the ending point for date and time range 2
The MEDIAN function is not capable of calculating a result based on an array of intervals, that is until now. The new Excel 365 BYROW function changes this, it is now possible to calculate overlapping date ranges across multiple intervals.
By employing two distinct BYROW functions, we can achieve the following:
- Iterate through all days within the specified date and time range.
- Iterate through each row in the day and night schedule.
This allows us to calculate both the total and a detailed breakdown of the total across all days in the given date and time range. Furthermore, it also enables the calculation of a breakdown of the total per row in the day and night schedule.
The array that displays the detailed breakdown of the total across days indicates no values for both Saturday and Sunday. This is accurate because the schedule does not contain any intervals for those particular weekdays.
The total in cell F21 has the following formatting applied: [h]:mm:ss This allows hours being greater than 24 which is the number of hours in one day. This format is useful for displaying long durations larger than 24 hours.
The WEEKDAY function enables us to calculate numbers representing the weekday starting from 1 (Monday) to 7 (Sunday) for each day in the date and time interval. This makes the data coherent to the day and night schedule that is based on weekday numbers. The MEDIAN function can use these values to calculate a time value that represents overlapping interval.
